Key Benefits
- Work station for bottom repair and cleaning
- Trailer rolls in or out past jacks, allowing you to take
boats on or off trailers easily
- Jacks have a Safety lock allowing boats to be left on
jacks indefinitely
- Jacks can be used on dirt, gravel, black top or cement
- Jacks can be used anywhere, Shop, yard, showroom
- Lifts boats up to 40,000 lbs. (with 4 jacks)
- 10 minute boat placement
- 20" vertical lift
- Lifts big boats right off the transport truck
- Allows fast and easy trailer to trailer exchange
- Expedite boat show setup. No waiting for a crane
|
Specifications
| Capacity Each Jack |
10,000lbs |
19" Height |
| Straight Arm Part# 012 |
|
|
| 1st Pin Hole |
8,000 "Per set of 4" |
33"-52" |
| 2nd Pin Hole |
16,000 |
33"-52" |
| 3rd Pin Hole |
24,000 |
33"-52" |
| 4th Pin Hole |
40,000 |
33"-52" |
| Drop Arms |
|
|
| 10" Drop Part# 014 |
10,000 "per set of 4" |
23.5"-42.5" |
| 15" Drop Part# 015 |
10,000 |
18.5"-37.5" |
| 20" Drop Part# 016 |
10,000 |
12.5"-31.5" |
| Big Boat Pads (Contact Pads) |
|
|
| Part# 019 |
For Boats over 15,000 Lbs. |
|
| Shipping Weight Per Set |
1425 Lbs. |
|
|
